Portable Display Coating Tester & Thickness Guage w/ HD Colour Screen


In stock

$249.90 $289.90

In stock

This colour-screen portable coating thickness gauge with high definition display can quickly, non-destructively and accurately measure coating thickness. It is widely used in manufacturing, metal processing industry, chemical industry, commodity inspection and other testing areas.


• Colour-screen HD display with menu operation available in 3 languages (English, Chinese and Russian)
• Thickness measurement of non-magnetic coating on magnetic metal substrate surface and non-metallic coating on non-magnetic metal substrate
• Single measurement and continuous measurement method
• Automatic substrate identification (magnetic metal and non-magnetic metal)
• Basic and Zero-point calibration
• MAX/MIN/AVG/DIFF value measurement
• Alarm function for High and Low limit value
• ON / OFF um & mil display unit
• Metric/imperial unit
• Data storage function 1500 items (15 items/set, max100set)
• Voice prompts function available in English, Chinese and Russian
• Screen display rotation
• Multi-interface display
• With Dot plot Data Analysis
• Screen brightness selection
• Automatic shutdown


• Measurement range: 0~1300um/51mil
• Resolution: [0.1μm(<100μm), 1μm( ≥100μm)]/0.1mil
• Measurement error: ≤150μm ±5μm / >150μm ±(3%H+1μm)
• Magnetic metal substrate

• Minimum diameter: 12mm
• Minimum thickness: 0.5mm

• Non-magnetic metal substrate

• Minimum diameter: 50mm
• Minimum thickness: 0.5mm

• Minimum radius of curvature

• Magnetic convex substrate: 2mm
• Magnetic concave substrate: 11mm

• Size: approx. 52.9 x 26 x 117mm
• Weight: approx. 102.4g

Set Includes

• 1 x Digital Colored Thickness Meter
• 1 x Iron Substrate
• 1 x Aluminum Substrate
• 6 x Calibration plates
• 1 x USB cable
• 1 x Lanyard
• Instruction Manual
